|Name:||Oxygen Compressor||Gas Type:||Oxygen|
|Machinery Test Report:||Provided||Power Source:||Diesel|
|Motor Power.:||15KW||Cooling Method::||Air Cooling|
|Compression Stages::||3 Stages||Package:||Wooden Case|
3m3 Oil Free Oxygen Compressor,
Hospital Oil Free Oxygen Compressor,
Air Cooling Oil Free Oxygen Compressor
1-3m3 green oil free oxygen compressor for hospital oxygen system
3m3 reciprocating oxygen compressor, oil-free high pressure oxygen compressor
The oxygen compressor is a compressor used to pressurize and transport or store oxygen.
The oil-free reciprocating oxygen compressor is suitable for inlet pressure 3-4barg (40-60psig) and exhaust pressure 150barg (2150psig) working conditions
The filling capacity is 3 cubic meters per hour and two-stage compression. It is recommended to work no more than 8 hours a day and fill 2-3 bottles each time.
Features of the compressor
Using two-stage compression, stainless steel cylinder, equipped with intake and exhaust pressure switches, high exhaust temperature protection. If the temperature is over-temperature and the pressure is over-pressure, the system will alarm and stop working to ensure safe operation. Small size, light weight and equipped with casters, very suitable for mobile use.
Our standard high-pressure oxygen compressor has passed the EU CE certification and meets the requirements of the EU market.
We can also provide customized oxygen compressors according to customer conditions.
Our oxygen compressor has the following characteristics
According to different working conditions of customers:
1. Completely 100% oil-free, no oil required, stainless steel cylinder
2. Suitable for VPSA PSA oxygen source pressurization
3. No pollution, keep the gas purity unchanged
4. The quality is safe and reliable, with good stability, comparable to and replacing similar foreign brands.
5. Low purchase cost, low maintenance cost and simple operation.
6. The service life of the piston ring under low pressure condition is 4000 hours, and the service life of piston ring under high pressure condition is 1500-200 hours
7. Brand motor, you can specify the brand, such as Siemens or ABB brand
8. Supply the Japanese market to meet Japan's demanding quality requirements
9. According to the customer's specific working conditions, the compressor is designed for single-stage compression, two-stage compression, three-stage compression and four-stage compression.
10. Low speed, long life, average speed 260-400RPM,
11. Low noise, the average noise is less than 75dB, can work quietly in the medical field
12. Continuous continuous heavy-duty operation, stable operation for 24 hours without shutdown (depending on the specific model)
|Model||Working medium||Intake pressure.barg||Exhaust pressure.barg||Nominal volume flow NM3/hour||Motor power.KW||Voltage frequency||Intake/exhaust
|Cooling method||Net weight kg||Size.mm||Compression stage|
|GOW-1.8/1-150||Oxygen||1||150||1.8||1.5||380/50/3||DN15/DN15||Air cooling||120kgs||700*650*650||Level 2|
|GOW-1.8/1-200||Oxygen||1||200||1.8||1.5||380/50/3||DN15/DN15||Air cooling||120kgs||700*650*650||Level 2|
|GOW-2.7/1-150||Oxygen||1||150||2.7||2.2||380/50/3||DN15/DN15||Air cooling||125kgs||700*650*650||Level 2|
|GOW-3/4-150||Oxygen||4||150||3||3||380/50/3||DN15/DN15||Air cooling||130kgs||700*650*650||Level 2|
